Taking your ATV out and riding on the trails with your friends or by yourself is quite an enjoyable hobby to spend your spare time. But what if the ATV suddenly stops while you ride? Battery dying is a common cause of ATVs suddenly breakdown. There are many reasons why the battery stopped working suddenly. Your ATV stator could be a cause too. How can you fix it? Or test it early and avoid the battery dying? Let us find out.
What is an ATV Stator?
To power accessories, light spark plugs, and refuel batteries, stators generate an electrical charge. Stators are coils of wrapped wire that generate DC electricity when moving, much like the alternator or generator in a car.
Process of an ATV Stator
What Does ATV stator Do?
A stator recharges the battery when an ATV is in use. It is an electrical part of the ATV. The components of stators are an iron core, wire coils, and a cable that connects them to the voltage regulator. Magnets move through the coils, producing an electric current in the wires. The voltage regulator receives this current after that, which charges your battery.
Where is the ATV stator location?
It emerges from the engine side cover. You must follow it to a block connector and disconnect it to remove it.
What are the ATV stator types?
There are three types of ATV Stators.
- Single Phase Stators : It makes the coils encircle the iron core out of a single wire.
- Three Phase Stators : The coils that encircle the iron core are made using three wires. There are three wires on the cable exiting the stator.
- Bar coiled stator : A small stator with coils organized and fastened to a backing plate. Instead of an iron core, the coils are linked to bars.
Many new ATVs use a three-phase stator because it produces more power. And older ATVs are more likely to have a bar coiled stator.
Bad Stator
If your stator is damaged, your battery will not charge while riding the ATV.
What are the signs your stator is bad?
A weak or dead battery is the most evident indication of a damaged stator. The stator could be to blame if your battery charges successfully on a different battery charger or has passed a more thorough inspection.
What happens when a stator goes bad?
You can only run your ATV until the battery dies if the stator fails.
Will a four wheeler start with a bad stator?
While the ATV is operating, the stator enables the battery to recharge. Your quad won’t operate if your stator is damaged since it would not have spark.
What are the Causes for bad stator?
so, when we think about What can damage a stator? mmm, lets see! Excessive loading while using the accessories. You would also overload the system if you tried to pull or plow simultaneously. This could cause the rectifier or stator to burn out.
How to Fix a Bad ATV Stator?
The best and most cost-effective way to fix an electrical system problem is to install a new stator. Depending on the specific ATV, install ATV stator replacements can be a much simpler course than trying to fix them because restoring stators can be a complex and detail-intensive process.
How much does a stator cost?
Stators have a wide price range in the current market. The highest-priced stator currently costs 470.73 dollars.
How to Test a Stator?
Here we tell you how to test your stator with a multimeter.
Why use a multimeter?
When you use a multimeter to test your stator, you can perform a quick resistance analysis on the port and compare the results to those in the manual. And as soon as possible, get a new stator if you receive an OL analysis.
Static Test
You must first carry out a static test, which is a test carried out without the engine running and the stator connected to the ATV. Before disconnecting the stator, ensure that the ATV is off. Start each circuit’s resistance testing with your multimeter’s ohms setting. Check the connections between pins 1 and 2, 2 and 3, as well as between 1 and 3 by simply attaching the leads from the multimeter to the terminals in the electrical connector of the stator. Check the multimeter reading against the recommended value in your service handbook.
To ascertain whether the stator is shorting to the ground, perform the following test. One meter lead will go in the connector, and the other will go on the stator body. OL, or open line, is the proper interpretation in this case. If you notice another reading, there is a problem with the stator. Measure the length of each coil, winding, and phase.
Dynamic Test
Performing the dynamic test while the motor is running is another test. You must charge your battery for this to function. You must have the AC voltage setting on your multimeter for this measurement. Probably, you will want a pal to assist you.
by attaching the terminals with the multimeter lead on the electrical connector for the stator; you can measure the distance between coils or pins while the engine is running. Once more, take your measurement between pins 1 and 2, 2 and 3, and between 1 and 3. A good reading is what you seek.
You can repeat this test with a higher engine RPM. In this instance, if you are expecting the reading between the terminals to rise as the RPM increases. A fault occurs if the voltage reading doesn’t change between the static and dynamic tests.
Frequent questions on ATV stator
ATV oil in stator cover?
It is a common question asked about stator cover. The stator runs on the engine oil. So, it is normal. You do not need to worry.
What is ATV stator output voltage?
The stator output varies with engine speed. The majority of bridge rectifiers have a minimum PRV rating of 100. So it would be 13 VAC.
Are your ATV stator wires getting hot?
Current (amperage) flowing through a resistance results in heat. More often than not, heat is generated at connections (which have higher resistance than continuous wire), although older or corroded wire will heat up more quickly than new wire. The output voltage decreases, the amperage rises, and heat is produced when the stator ages and is subjected to heavy loads.
The Bottem line
An ATV stator has two primary purposes: it charges the battery, and, using a unique coil attached to the stator, it also charges the CDI device. This coil then releases that energy to start the engine. Like a car generator, the stator of an ATV charges the battery while it is in motion. The electrical system of an ATV cannot function without an ATV stator.
